economical kind light economical kind flood light economical kind project
YPMY 30-400W
Product characteristics:
Good quality of the powder coating, not easy to scratch.
Automatic glue machine , 100% pass the water testing.
Good appearance, careful attention to the details.
Good quality of the powder coating, not easy to scratch.
Automatic glue machine , 100% pass the water testing.
Good appearance, careful attention to the details.
Quantity
| SPECIFICATION | YPMY30 | YPMY50 | YPMY100 | YPMY150 | YPMY200 | YPMY300 | 400w |
| economical kind light Wattage／瓦数 | 30w | 50w | 100w | 150w | 200w | 300w | 400w |
| economical kind light DIMENSION(MM)／产品尺寸 | 148*123*23.8 | 205*160*25 | 270*210*25 | 32.9*24.8*25 | 37.8*28*25 | 42.5*31.5*27 | 47*36*28 |
| economical kind light Materials／材质 | ALU＋LENS | ALU＋LENS | ALU＋LENS | ALU＋LENS | ALU＋LENS | ALU＋LENS | ALU＋LENS |
| economical kind light Water Proof／防水等级 | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 |
| economical kind light Power／实际功率 | 90% | 90% | 90% | 90% | 90% | 90% | 90% |
| economical kind light POWER FACTOR／功率因数 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 |
| economical kind flood light economical kind project Driver／DOB | DOB | DOB | DOB | DOB | DOB | DOB | DOB |
| economical kind flood light economical kind project Voltage／电压 | AC100-265v | AC100-265v | AC100-265v | AC100-265v | AC100-265v | AC100-265v | AC100-265v |
| economical kind light economical kind flood light economical kind project CRI／显指 | 80 | 80 | 80 | 80 | 80 | 80 | 80 |
| economical kind light economical kind flood light economical kind project EFFCIENCY(LM/W) | 90lm/w | 90lm/w | 90lm/w | 90lm/w | 90lm/w | 90lm/w | 90lm/w |
| economical kind light economical kind flood light economical kind project EMC | ／ | ／ | ／ | ／ | ／ | ／ | ／ |
| economical kind light economical kind flood light economical kind project LED MODEL／灯珠型号 | SMD 2835 | SMD 2835 | SMD 2835 | SMD 2835 | SMD 2835 | SMD 2835 | SMD 2835 |
| economical kind light economical kind flood light economical kind project LED quantity／灯珠数量 | 36 | 60 | 120 | 180 | 240 | 360 | 420 |
| economical kind light economical kind flood light economical kind project SURGER／浪涌 | 2.5KV | 4KV | 4KV | 4KV | 4KV | 4KV | 4KV |
| economical kind light economical kind flood light economical kind project VOLTAGE RESISTANCE／耐压 | 1.5kv | 1.5kv | 1.5kv | 1.5kv | 1.5kv | 1.5kv | 1.5kv |
| economical kind light economical kind flood light economical kind project BEAM ANGLE／发光角度 | 90 | 90 | 90 | 90 | 90 | 90 | 90 |
| economical kind light economical kind flood light economical kind project WORK TEM. | -20～50℃ | -20～50℃ | -20～50℃ | -20～50℃ | -20～50℃ | -20～50℃ | -20～50℃ |
| economical kind light economical kind flood light economical kind project PCS/CTN／装箱数 | 20 | 20 | 20 | 10 | 5 | 5 | 5 |
| CTN SIZE（CM）／外箱尺寸 | 34.5x31x18 | 47.1X37X19.5 | 47.5x37x30.5 | 37x36.2x28.8 | 40.7x19.5x31.8 | 45.6x19.5x35.5 | 50.5x20x40 |
